SEI's RPS48VQ

48v System: 1-5HP Pumps OR moderate to heavy off grid living



-Pylontech 48v US5000 LiFePO4 battery x 4

·  Recommended Current = 80A (320A) = 15,360 watts

·  Max Current = 100A (400A) = 19,200 watts

·  Peak Current (15sec.) 200A (800A) = 38,400 watts

-19,200 total watt hours

-18,240 useable watt hours

-2 x Victron Quattro 48v 5kva Inverters

·  120v & 240v output!

·  Continuous Output power at 77F = 4,000w (8,000w total)

·  Continuous Output power at 104F = 3,700w (7,400w total)

·  Peak Output power = 10,000w (20,000w total)



-18 x 410w solar panels – 7,380 watts

***Additional solar options available up to 14,760w

-Midnite Solar combiners and breakers

-Victron 250/100 Charge controller

-Victron Cerbo GX and Touch 50

-1 year Victron Remote Monitoring included for free!

-Lynx Distributor system with Mega Fuses

-50A Generator input (30A adapter included)

·  50A cord included!

-Inverters have integrated transfer switching from grid to generator

-120v GFCI outlet on box

-AC input and output breaker boxes with Square D breakers

-Ruuvi Sensors for Temp and Humidity reporting

-AC Infinity active powered cooling register

-Power station comes pre-wired, tested and ready for installation! Simply bring Grid (if applicable) to the provided breaker panel, and wire your loads to the output breaker panel!

​

An All-In-One power station in a 4-Way; Caster-Ready; Pre-Punched Skids with 7-Gauge Construction Allow Access From any Side and Easy Installation of Optional Casters; Heavy-Duty 16-Gauge Steel Chest Box Construction with Fully Arc-Welded Seams; Heavy-Duty Recessed Side Gang Box Handles Allow for Enhanced Mobility and Protection Against Damage in Transport; Powder-Coat Finish for Superior Durability and Corrosion Resistance

​

-Ground and roof mounted solar options available--
